High Speed KFC Food Paper Bag Making Machine Automatic 180 - 430mm Width

Specifications :

Description :

PRY1200CS-430 sheet-feeding paper bag making machine(Adopt Italy technology) is suitable for the mass bag production, it is the first choice of medium and top grade handbag device. The product adopts mechanical,electricity, light, gas integration technology, setting a number of its proprietary technology, use the creased sheet paper as raw material,can one-time finish:paper feeding, positioning, top folding,tube forming, gusset forming, square bottom folding and gluing automatic, and then compaction output.The variable speed drive technology, combined with the system of vertical and horizontal creasing, bottom folding realize trackless bag molding process. using the PLC programmable control, frequency control technology to realize the integral multi-dimensional control, more centralized control and single point remote control operating system . with characteristics of good quality and high efficiency,its technology ranks leading level in domestic similar products.

Suitable paper :

Suitable Paper: Kraft paper, art paper(including film adhesive paper)
paper need pre-creasing

Machine configuration :

1. Feeder: enhanced prestack paper feeder to realize non stop paper feeding,greatly save the time to load and adjust raw paper.
2. Front and side guides positioning system
3. Top folding system
4. Both water soluable cold glue and hot melt glue
5. Formation version making gusset system
6. Screw rod to adjust bottom clip system
7. Bottom catch bag roller paper bag fall down alert system
8. Automatic collection system:Automatic counting,convenient to collect bags.

Technological process :

Selection and other

Feeder : enhanced prestack paper feeder to realize non stop paper feeding,greatly save the time to load and adjust raw paper.

Optional comfiguration Nordson hot melt adhesive system : fast adhesion product ,quickly enter the next process.

Screw rod adjusting bottom clip system :
help to shorten the adjusting time and improve the production efficiency in making handbags with different specifications.

Automatic collection system:
Can realize the automatic counting,convenient products collection.

optional confirguration bag compaction table: layers compaction bag device,fast adhesion,compaction, overlapping output,convenient collection,improve work efficiency.
