Electronic Semi Automatic Paper Cutting Machine For Big Area Hot
Stamping
Specifications :
Model | TYMK750 | TYMK930 | TYMK1040 | TYMK1100 | TYMK1200 | TYMK1300 | TYMK1400 | TYMK1500 |
Max . die cutting size(mm) | 750*520 | 930*660 | 1040*720 | 1100*800 | 1200*820 | 1300*920 | 1400*1000 | 1500*1040 |
Max . foil stamping size (mm) | 740*510 | 930*640 | 1040*720 | 1100*800 | 1200*820 | 1300*920 | 1400*1000 | 1500*1040 |
Foil length(mm) | 520 | 640 | 720 | 800 | 820 | 920 | 1000 | 1040 |
Moto power | 2.2Kw-6H | 4Kw-4H | 4Kw-4H | 4Kw-6H | 4Kw-6H | 7.5Kw-6H | 7.5Kw-6H | 7.5Kw-6H |
Power (Kw) | 10.2 | 16.5 | 16.5 | 20.5 | 20.5 | 28.5 | 28.5 | 28.5 |
Weight (Kg) | 2200 | 3500 | 3800 | 4700 | 5000 | 6500 | 7000 | 7500 |
Speed (pcs/min) | 26±3 | 23±2 | 23±2 | 20±2 | 20±2 | 15±2 | 15±2 | 15±2 |
Foil groups | 2 | 3 | 3 | 3 | 3 | 3 | 3 | 3 |
Heating area | 4 | 5 | 5 | 5 | 5 | 5 | 5 | 5 |
Overall dimensions(mm) | 1450* 1900*1950 | 1800* 1900* 2150 | 1800* 1950*2150 | 2150* 2150*2300 | 2150* 2250*2300 | 2200* 2300*2300 | 2300* 2350*2300 | 2400* 2400*2300 |
Description :
The computerize foil stamping and die cutting machine is new
generation of high precision and high effective innovative
products,mainly suiable for hot stamping all kinds of colored
aluminum foil, pressing the concave and convex and cutting various
pictures trademarks, product catalog advertising, cartons, books,
cover, new yearcards and other decorating, printing products. Ideal
processing equipment for the printing, packaging and plastic
industries.
Features:
. Adopt Taiwan PLC driver control,high precision, easy to
operate,stable performance
. Stepping motor has large torque,can be set to the desired size,to
be accurate, stable, reduce waste
. Having upper and lower delay, traveling ,jogging and the
temperature control etc
. Ther are independent speed motor in feeding and delivery device
to make feeding and delivery more convenient and practical
. The roller used aluminum alloy material,Processed through a
special process. It has light weight but high precision, reduce the
running load to extend service life
. Optional honeycomb board to make heating more evenly and quickly,
easy to adjust plate
. Heating adopt stainless steel,more durable
