Flute Laminator Machine , Industrial Book Lamination Machine
Specifications :
| Type | ZTC-700B | ZTC-900B |
| Max size | 450mm×720mm | 450mm×950mm |
| Min size | 130mm×210mm | 130mm×210mm |
| Board thickness | 1.0-3.0mm | 1.0-3.0mm |
| Paper weight | 100-200g | 100-200g |
| Max speed | 20-30Pieces/min | 20-30Pieces/min |
| Machine power | 13.5kw/380v | 13.5kw/380v |
| Machine size | 6500×2600×1850mm | 7500×2600×1850mm |
| Machine weight | 2300kg | 2500kg |
| Positioning accuracy | ± 1mm | ±1mm |
Introduction:
ZTC-700/900B Automatic Inner Laminating Machine uses servo drive,
optical scale positioning, hydraulic corrction and new technoloy as
well. This machine can finish automatically the inner paper
feeding, gluing, cardboard feeding and pre-flattening processes
with high accuracy, fast speed and high quality product and
provides inner laminating products solution at first time in the
printing and packaging industry.
Paper materials: printing paper, embossed paper, coated paper,
synthetic paper, fabric.
At the end of paper raw material: thick cardboard, plywood,
corrugated paper, thin wood, stone panels, plastic panels and so on
hard board.
Glue material: animal glue or cold glue
Main specification:
Import optical axis, linear guide, linear motion units
Japanese Omron PLC
German light-sensing element
Japanese Panasonic servo control system
Import pumping Dispensing Systems
Features:
Unique double-control device, an effective solution to double
sheets and a number of issues
With novel structure and reasonable to the digital device, can
effectively and accurately quickly cardboard composite tissues
Reasonably user-friendly design, the machines for a substantial
increase in plate efficiency
Stable and reliable mechanical transmission, high quality
electrical components makes the overall performance is stable and
reliable
Touch interface and machine malfunction display, making it more
convenient for man-machine dialogue
